Description
Length 53' Width 102" Top Deck Length 10' 5" (Plus 3' with flip box) Main Deck Length 33' 7" Closed / 59' 11" Open Main Deck Height 20" Loaded Deck Height Rear Deck Length 9' Weight 25,280 Lbs +/- 3% - GVWR 105,280 Lbs Flat Body Compatibility Designed to Accept 36" Neck Extention & Flip Axle Floor 1 1/8" Apitong Side Rail Perimiter Beam - Steel Outriggers Swingout Removable on 24" Centers, Double Front D-Rings Eight (8) Pair Bent D-Rings Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights 4" Amber Strobe w/ Switch for 3rd Tail Light Flag Holders Two Pair, Front & Rear Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 49" w/ Seven (7) Variable Ride Height Positions Pony Motors 13HP Honda Pony Motor, Dual Hydraulics Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54" Axle Spacing Flip Axle Components for Hydraulic Flip Axle Manual Dumpvalve Yes Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Aluminum Outside / Steel Inside Liquid Filled Gauge Yes UnderFrame King Pin Setting 16" Cross Member Center 4" I-Beam & Knee Braces on 12" Alternating Centers Paint Black Weight Ratings 80,000 lbs. distributed 60,000 Lb. Capacity in 10' Closed Chain Slots on 24" Centers 4" Tapered Front Approach Ramps Extension Stops on 24" Centers Includes 36" Flip Neck Extension Air Lock Pins at Rear to Pin on Hydraulic Flip Axle
