Description
40 Ton Hydraulic Full Width Neck Mini Deck. Trailer has the XL Specialized Classic Style Neck. This has 7 ride height positions and more stroke compared to the standard Scraper Neck. Flip axles and flip boxes available at additional cost. Length 53' Width 102" Top Deck Length 10' 5" Classic Neck, Full Width Neck Main Deck Length 33' 7" with 32' 11" Clear Deck Main Deck Height 12" with 4" ground clearance Rear Deck Length 9' Unit Description 40 Ton Hydraulic Mini Deck Flat Body Compatibility Designed to Accept 36" Neck Extention & Flip Axle Floor Apitong Side Rail Perimiter Beam - Steel D-Rings 15 Pair Strobe Lights Yes with battery back up Flag Holders One (1) Pair Rear Bogie Covered with 1 1/8" Apitong Decking Flush Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Pony Motors 13 HP Honda Pony Motor Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Hendrickson Suspension Setting 54" axle spacing Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Aluminum/Steel Liquid Filled Gauge Yes UnderFrame King Pin Setting 16" Cross Member Center 12" centers Paint Black Weight Ratings 40 Ton -84" Swing Clearance -49" 5th Wheel Height with 5 variable ride height adjustments -Full Width Neck with 1 1/8" Apitong Decking, Flush -Steel decking between main beams with Durabak -Manual Ride Height Control Valve -4 way plug at rear -Provisions for 3rd axle flip
