Description
THIS TRAILER IS THE BOTTOM TRAILER! Length 52' 5" Width 102" Top Deck Length 11' 11" Gooseneck Main Deck Length 26' Main Deck Height 14.5" at Side Rails; 23" at Main Beams Weight 24,784 Lbs. +/-3% Unit Description Magnitude 60DSR Compatibility Designed to Accept Flip Neck Extension & Flip Axle Floor 1.5" Nominal Wood - Side Rails Only Side Rail Drop Side Rail - Steel Outriggers 13 Pair, Removable Swing Type D-Rings 19 Pair Toolbox Two Covered Trays Between Mainbeams Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Amber Strobes with Battary Power Flag Holders One Pair at Front of Deck, One Pair on Bumper Modular Connection Fixed Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Axle Spacing Lift Axle Air Lift Rear Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels Aluminum/Steel Liquid Filled Gauge Yes Paint Red Weight Ratings 60 Ton in 13' Length w/ Closed 4-Axle Hammer Plate (16"x60"x1/2") installed over recessed crossmembers. Perforated plate under hammer plate forming two storage areas. 2 lashing rings located in last two deck sections.
