Description
Length 54' 9" Width 102" Top Deck Length 12' 8" Gooseneck Main Deck Length 28' Main Deck Height 14.5" at Side Rails; 23" at Main Beams Weight 25,781 Lbs. +/-3% Unit Description Magnitude 60MDSR Flat Body Compatibility Accepts 36" or 83" Neck Ext, 51/60 Flip & Spreader Floor 1.5" Nominal Wood - Side Rails Only Ramps None, Front Deck Sloped Down Side Rail Drop Side Rail - Steel Outriggers 13 Pair, Removable Swing Type D-Rings 17 Pair Toolbox Two Covered Trays Between Mainbeams Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Amber Strobes with Battery Power Flag Holders Two Pair Modular Connection Modular Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel Dual Cam Pawl Arm w 7 Ride Height Positions, 50" Suspension # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Axle Spacing Lift Axle Air Lift Rear, Chain Lift Front Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels Aluminum/Steel Liquid Filled Gauge Yes UnderFrame Paint Black Weight Ratings 60 Ton in 12' Length Comments 106" Swing Radius Flip Axle sold Separately Sale Price Includes FET
Features
...
