Description
Length 54' 9" Width 102" (Suspension) Main Deck Length 28' Main Deck Height 23" Weight 22,641 Lbs. Unit Description Beam Trailer Flat Body Compatibility To Accept 36" or 83" Neck Extention & Flip Axle Floor N/A - Beam D-Rings 17 Pair Toolbox 2 Trays - Fully Covered Between Main Beams Side Rail Lights (3) Marker Lights per Side incl. Mid-Turn Rear Lights (3) Stop/Tail, (3) Clearance Strobe Lights Battery Powered Rear Amber Strobes Flag Holders 2 Pair Modular Connection Modular Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 50" with Five Ride Height Positions Suspension # of Axles 3 Suspension Type Air Ride Suspension Setting 54.5" Axle Spacing Lift Axle Rear Axle Air Lift, Chain Lift on Front Axle Flip Axle Not Included Manual Dumpvalve Yes Raise & Lower Valve Mechanical Ride Height Control Valve Tire Size 275/70R22.5 Wheels Aluminum Polished Outside, Steel Inside Liquid Filled Gauge Yes UnderFrame King Pin Setting 16" & 36" Cross Member Center 24" Centers Paint Black Weight Ratings 60 Ton in 12' Length Comments Swing Radius of 86" or 106" 12' 8" Overall Gooseneck Length Set for Wet LIne Operation Page 1 of 1SMU20420
