Description
Length 48' 6" Width 102" Top Deck Length 12' 6" Main Deck Length 24' Main Deck Height 24" Loaded Rear Deck Length 11' 11" Weight 19178 Flat Body Floor 1 1/2" Apitong (Mesh Center) Ramps 36" Wood Rilled Spring Assist Front Ramps Side Rail Perimiter Beam - Steel Outriggers 24" Centers (Locks both in & out position) D-Rings ROTO style.(5) siderail, (1) Bolster Rear Lights (2) Stop/Tail, (3) Clearance Strobe Lights Amber Strobe with Battery Flag Holders One Set at Rear Gooseneck Gooseneck Hydraulic Detachable, Non-Ground Bearing Loaded 5th Wheel 50" Suspension # of Axles 2 Suspension Type Air Ride Suspension Brand Ridewell Suspension Setting 54" Axle Spacing Manual Dumpvalve Yes Raise & Lower Valve Yes Tire Size 255/70R22.5 Wheels Steel UnderFrame King Pin Setting 15" Cross Member Center 10" Deep, 18" Centers Paint Black Weight Ratings 35 Ton Comments 4" Riser (16'Slope) Wood in Center of Trunnion Wood in Center of Trunnion Riser Slope 90' Swing Clearance Roller Stop on Tailboard
